Digital Solar Charge Controller with Intelligent Charging, Anderson Connector, and LCD Display for Efficient Energy Management

Name: Digital Solar Charge Controller with Intelligent Charging, Anderson Connector, and LCD Display for Efficient Energy Management
Brand: Shenzhen Melin Sunergy Co., Ltd.
SKU: MT518-30A
Price: 58.00 USD
Availability: InStock

Nombre De La Marca:	Melin Sunergy
Número De Modelo:	MT518-30A
Cuota De Producción:	300
Capacidad De Suministro:	5000pcs Per Month

Información detallada

Descripción de producto

Información detallada

Certificación:

CE ,FCC ,UKCA

Nivel IP:

IP65

Corriente nominal:

30Amp

Diseño especial:

Fijación de imanes

Mostrar:

LCD

Color:

Gris + Rojo

Baterías:

Se aplicará el método de medición de los niveles de CO2 en el agua.

Potencia máxima de entrada solar:

600W

Funciones de protección:

Sobrecarga, cortocircuito, polaridad inversa, sobrecarga

Supply Ability:

5000pcs Per Month

Resaltar:

Intelligent Charging Digital Solar Charge Controller

Anderson Connector PWM Solar Charge Controller

LCD Display Solar Charge Controller

Descripción de producto

Digital Solar Charge Controller with Intelligent Charging

The 600W Digital Solar Charge Controller is an advanced PWM controller designed for optimal energy management in 12V solar systems. With a 30A rated current and 25V maximum solar input, this IP65-rated controller features intelligent charging technology specifically engineered for Lithium batteries (LiFePO4) while also supporting AGM, GEL, WET, Calcium, and LTO battery types.

Key Features

Advanced PWM charging technology for efficient energy regulation
Robust IP65-rated enclosure for dust/water resistance
Comprehensive protection: overload, short circuit, reverse polarity, overcharge
Convenient Anderson connector and magnetic mounting system
Clear LCD display for real-time system monitoring
Compact grey/red design suitable for various installations

Technical Specifications

Parameter	Specification
Controller Type	PWM
Maximum Solar Input Power	600W
Rated Current	30A
Maximum Solar Input Voltage	25V
System Voltage	12V
IP Rating	IP65
Supported Battery Types	AGM/GEL/WET/Calcium/LTO/LiFePO4

Applications

Ideal for residential, commercial, and off-grid solar systems including RVs, boats, remote cabins, and small-scale solar installations. The durable IP65 rating makes it suitable for harsh outdoor environments while the compact design works well in space-constrained applications.

Certifications & Compliance

CE, FCC, and UKCA certified for quality assurance and international compliance standards.

Ordering Information

Model: Melin Sunergy MT518-30A
Minimum Order Quantity: 300 units
Monthly Capacity: 5000 units
Lead Time: 25 days

Frequently Asked Questions

What battery types does this controller support?

The controller is compatible with AGM, GEL, WET, Calcium, LTO, and Lithium (LiFePO4) battery chemistries.

Is this controller suitable for outdoor installation?

Yes, the IP65 rating provides protection against dust ingress and water jets from any direction.

What is the warranty period?

Please refer to the manufacturer's warranty documentation included with your purchase.
